74 SERIES

Thesedevices contain six independent inverters. To perform correctly, the open-collector outputs require pullup
resistors.
These devices may be connected to other open-collector outputs to implement active-low wired-OR
or active-high wire-AND functions. Open-collector devices often are used to generate high V
OH levels.
