LED Digital Voltmeter DC 5V – 30V dsn-dvm-568

LED Digital Voltmeter DC 5V – 30V dsn-dvm-568

Description:

1. This voltmeter has a wide range of 5-120V DC, suitable for 12V, 24V, 36V, 48V, 60V, 72V, 80V, 96V motorcycles, electric vehicles, battery cars, and other voltage measurement purposes.

2. Equipped with two wiring, direct measurement, no auxiliary power supply. It can be easily connected to vehicle, battery car, motorcycle and other vehicle lines. With reverse connection protection function, the line connection will not burn.

3. The measuring precision of this voltmeter can be adjusted automatically. The resolution is 0.1V below 100V and 1V above 100V.

4. The voltmeter is designed with ABS plastic frame, which can be conveniently installed in rectangular holes of 1.5-3 mm thickness.



Features:

High precision.
Low operating voltage.
With reverse protection, then anti-burn.
Ultra-high pressure 132V does not burn.



Specifications LED Digital Voltmeter

Dimensions: 35mmx14mmx10mm
Measurement accuracy: 1%
Refresh rate: about 200mS / times
Display: Three 0.36 “digital tube
Measuring range: DC 3.2V-30V (Can Measure Power Supply 3.2-30V Directly)
Input range: DC 3.2V-30V
Display Color: Blue
Operating current: Less than 20mA
Operating temperature: -10°c -65°c
Input impedance: About 100K

Red: Power Supply +, Measure +
Black: Power Supply -, Measure –
