ESP-12F ESP8266 Serial WIFI Module

ESP8266-12 is an enhanced version ESP8266-12, improve peripheral circuitry increases impedance matching, the signal output is better, whether it is stable or anti-jamming capability, have been greatly improved! For users before selecting the ESP-12, it does not matter even if the product has been made, enhanced version is fully compatible with previous firmware, the pin has added six IO ports on the basis of the ESP-12, SPI leads.

Features:

• 802.11 b/g/n
• Wi-Fi Direct (P2P), soft-AP
• Integrated TCP/IP protocol stack
• Integrated TR switch, balun, LNA, power amplifier and matching network
• Integrated PLLs, regulators, DCXO and power management units
• +19.5dBm output power in 802.11b mode
• Power down leakage current of <10uA
• Integrated low power 32-bit CPU could be used as application processor
• SDIO 1.1 / 2.0, SPI, UART
• STBC, 1×1 MIMO, 2×1 MIMO
• A-MPDU & A-MSDU aggregation & 0.4ms guard interval
• Wake up and transmit packets in < 2ms
• Standby power consumption of < 1.0mW (DTIM3)
